SCIR40 - Special circular lnb.

In Stock

237,00 kr

More info

SCIR40 - Special circular lnb.

  • Suitable for commercial installations.
  • Works for all circular polarity satellites.


Specs:
Input Frequency Range: High Band : 11.7 ~ 12.75 GHz
Output Frequency Range: 750 ~ 2000 MHz
L.O. Frequency: 10.75 GHz
L.O. Frequency Stability: +/-1 MHz (Max)@ Room Temp.

Local Oscillator Frequency Phase Noise:
-60dBc/Hz @ 1KHz (Max.)
-85dBc/Hz @ 10KHz (Max.)
-105dBc/Hz @ 100KHz (Max.)

Noise Figure: 0.2dB (Typ.)
Conversion Gain: 56 ~ 60 dB
Gain Flatness 26MHz Bandwidth: +/-0.5dB (Typ.)

Operating Voltage:
RHCP 11.0 ~ 14.0 Vdc
LHCP 16.0 ~ 20.0 Vdc

Cross-Pol. Isolation: 25 dB (Typ.)
Image Rejection:40 dB (Min.)
Current Consumption:90 mA (Typ.)
Output Connector Type:75 OHMS F-Female
Output Spurious: <-60dBm
Operating Temperature Range: -40°C ~ +65°C
Storage Temperature Range: -45°C ~ +70°C
